Food & Beverage Industry
VAF 500 self-cleaning filter efficiently removes TSS to increase water quality
Problem Statement
The client was experiencing a high amount of TSS coming through their feed water supply from the municipality. Their current system was not able to provide the desired quality of product water and took a significant time to clean the strainers because this process was previously done manually. This also meant the line needed to be isolated and the strainer disassembled, cleaned and then re-assembled.
Solution
Watericon supplied, installed and commissioned a VAF automatic self-cleaning strainer, which is able to clean itself on both a time basis and through automatically measuring the differential pressure over the feed and product. VAF self-cleaning filters can remove particles between 10 to 1500 microns.
Concentrate losses
- 25 seconds of flush every hour. Equating to a 0.7% loss.
- As the system is set up to flush based on time and differential pressure we can assume that the loss is around 1%.
Performance Target
- The client wanted a system that would work without them having to pause the system to keep attending to blockages.
- This was achieved with the system being able to trigger the back flush automatically
Process
- Straining
- Removal of TSS above set micron rate
Innovation
Automated self-cleaning strainer, requiring no additional flush or backwash pump or motor.
